TE-10P-MD Mag Drive Pump
| Unit | 60Hz | |
|---|---|---|
| System | US | Metric |
| Max Flow | 200 GPM | 757 LPM |
| Max Head | 160 FT | 48.7 M |
| Power | 10 HP | 7.46 KW |
| 50Hz | |
|---|---|
| US | Metric |
| 172 GPM | 654 LPM |
| 112 FT | 34.1 M |
| 10 HP | 7.46 KW |
Electrical/Air: 3Ph 230/460V 60Hz & 380V 50Hz, or 3Ph 575V 60Hz
Inlet: 3″MPT
Outlet: 2″MPT
- Wet End: Polypropylene(Front Housing, Rear Housing, Impeller), Viton (Gasket), Carbon (Bushing), Ceramic (Shaft, Thrust Washers)
- Additional Motor Options: Available in 10HP Explosion Proof, 575V, and Washdown
- Max Internal Pressure: 75 PSI / 5.2 bar
- Max Liquid Temperature: 190 °F / 87 °C
- Note: Product image may be different than actual product received.
