SP-700-SR Drum Pump from Standard Pump

The SP-700-SR drum pump is engineered specifically for transferring viscous materials from drums and tanks commonly found in the industrial marketplace. The progressive cavity design deliverers a continuous, smooth flow of material with little product degradation. Maximum viscosity is 25,000 cps (mPAS).

Category:

The SP-700-SR drum pump is engineered specifically for transferring viscous materials from drums and tanks commonly found in the industrial marketplace. The progressive cavity design deliverers a continuous, smooth flow of material with little product degradation. Maximum viscosity is 25,000 cps (mPAS).

Common Applications:
> Polymers
Oil & Greases
> Resins
> Paints
> Adhesives
Varnishes



Technical Data :
Design:
Seal-less / Centrifugal
Max. Viscosity:
25,000 cps (mPAS)
Dishcharge Port:
1.5″ / 38mm hose barb
Mechanical Seal:
Silicone Carbide
Stator Materials:
Teflon, Viton or Buna-N
Immersion Lengths:
27″ (700mm)
39″ (1000mm)
47″ 1200mm)
Wetted Materials:
Tube & Rotor Assembly: 316 Stainless Steel Stator Material: Teflon, Viton, or Buna
Motor Drives:
SP-ODP, SP-280P, SP-ENC, SP-400-2, SP-A2.
Consult chart for viscosity ratings and performance curves(PDF)
Fittings:
Large Type Acme Thread design enables
operator to disassemble pump quickly for cleaning, maintenance, and inspection.
Maximum
Flow Rate:

17GPM / 64 LPM
Pressure:

174 psi / 12 bar
Benefits:
  • Easy Maintenance
  • Threaded Components
  • Interchangeable Motors Drives
  • Continuous Flow
  • Low Shearing Properties
Motor Drives :
• SP-ODP SERIES
• SP-ENC SERIES
• SP-280 SERIES
• SP-400 SERIES
• SP-A2 SERIES

Motor Drives

Consult chart for viscosity ratings and performance curves(PDF)





Warning: When pumping flammable or combustible liquids pump tube must be
used in conjunction with an explosion proof motor.
