Sanitary Drum Pumps – Standard Pump SP-800-DD

The SP-800-DD sanitary drum pumps are engineered specifically for transferring viscous materials from drums and tanks commonly found in the Industrial Market place. The progressive cavity design delivers continuous flow of material with little product degradation. Maximum viscosity is 100,000 cps (mPAS).

Category:

The SP-800-DD sanitary drum pumps are engineered specifically for transferring viscous materials from drums and tanks commonly found in the Industrial Market place. The progressive cavity design delivers continuous flow of material with little product degradation. Maximum viscosity is 100,000 cps (mPAS).

Common Applications:
> Pie Fillings
Chocolate
> Juice Concentrates
> Lotions
> Tomato Paste
> Shampoo



Technical Data :
Design:
Progressive Cavity / Positive Displacement
Max. Viscosity:
100,000cps (mPAS)
Dishcharge Port:
1.5” / 38mm Tri-Clamp Fitting,
optional 1.25” /32mm
Stator Materials:
Sanitary Teflon or Buna-White
Mechanical Seal:
SiC/Viton/SiC
Immersion Lengths:
27″ (700mm)
39″ (1000mm)
47″ 1200mm)
Please add 6” (150mm) to the Immersion
length of pump for the 752 series pumps.
Wetted Materials:
Tube & Rotor Assembly: 316 Stainless Steel
Stator Material: Sanitary Teflon & Buna -White
Pump Finish:
316 SS Polished to 32 Ra
Motor Drives:
Food processing / epoxy coated pneumatic or electric motors are available in 50 & 60 Hz, 230, 380, 415 & 460v
Consult chart for viscosity ratings and performance curves(PDF)

Fittings:
Large Type Acme Thread design enables operator to disassemble pump quickly for cleaning, maintenance, and inspection.
Mounting
Flange:
B14/C140-160
Maximum
Flow Rate:

17GPM / 64 LPM
Pressure:

174 psi / 12 bar
Benefits:
  • Hygienic Design
  • Easy to Clean & Maintain
  • Gentle Product Treatment
  • Continuous Flow
Motor Drives :
• Sanitary Electric
230/460V/3/50-60Hz
• Sanitary
Pneumatic Motors

Industrial Motor Drives

Consult chart for viscosity ratings and performance curves(PDF)



Warning: When pumping flammable or combustible liquids pump tube must be
used in conjunction with an explosion proof motor.
