CPVC Pump Tube Sets from Standard Pump

STANDARD’s CPVC pump tube is engineered for transferring corrosive chemicals associated with the water treatment industry. Robust CPVC offers excellent durability and chemical resistance.

Category:

STANDARD’s CPVC pump tube is engineered for transferring corrosive chemicals associated with the water treatment industry. Robust CPVC offers excellent durability and chemical resistance.

Applications:
> Sodium Hypochlorite
>Calcium Hydroxide
>Calcium Chloride
>Chlorinated Water
>Potassium Hydroxide
>Sodium Bromide



Technical Data :
Design:
Seal-less / Centrifugal
Viscosity:
1500 Cps/mPas (280, ENC, 400)
750 Cps/mPas (A-2, ODP)
450 Cps/mPas (A-1)
Wetted Materials:
CPVC
Carbon
Hastelloy
Discharge Options:
1″ (25mm) barb
3/4″ (22mm) barb
Maximum Temp:
190°F/90°C
Maximum
Specific Gravity:

1.8
Model
Tube Assembly
Length
Shaft
Impeller
SP-CPVC-27
CPVC
27″ (700 mm)
Hastelloy
High Volume
SP-CPVC-39
CPVC
39″(1000 mm)
Hastelloy
High Volume
SP-CPVC-47
CPVC
47″ (1200 mm)
Hastelloy
High Volume
SP-CPVC-60
CPVC
60″ (1400 mm)
Hastelloy
High Volume
SP-CPVC-72
CPVC
72″ (1800 mm)
Hastelloy
High Volume
SP-CPVC-HH-27
CPVC
27″ (700 mm)
Hastelloy
High Pressure
SP-CPVC-HH-39
CPVC
39″ (1000 mm)
Hastelloy
High Pressure
SP-CPVC-HH-47
CPVC
47″ (1200 mm)
Hastelloy
High Volume
SP-CPVC-HH-60
CPVC
60″ (1400mm)
Hastelloy
High Volume
SP-CPVC-HH-72
CPVC
72″ (1800 mm)
Hastelloy
High Pressure
