62 HD Series

Covered by US Patent Number 6,364,620.

APPLICATIONS

  • Pumping stations
  • Storm water removal
  • Wastewater transfer
  • Industrial wastewater

PUMP:

  • Solids: 3” (76 mm) spherical capability
  • Discharge: 4” & 6” flanged horizontal
  • Seals – dual mechanical carbon/rotary ceramic/stationary, Buna-N elastomers
  • Construction – cast iron ASTMA A-48, Class 30, 30,000# tensile strength, protected with a corrosion-resistant, baked-on epoxy powder coating
  • Attaching hardware – 304 stainless steel
  • O ring elastomers – Buna-N
  • Impeller – 2-blade, semi-open ductile impeller with top pump out vanes
  • Moisture-detection system
  • Optional:
    • Silicon carbide seal(s)
    • Vortex impeller
    • Bronze impeller
    • Trimmed impeller
    • Additional cord length
    • Dry pit configuration
    • High temperature construction
    • Inverter duty motors
    • Rail systems

MOTOR:

  • Stator – Class F insulation and lead wires, NEMA B design
  • Thermal sensor and leads
  • Housing – Class 30 cast iron, finned, oil-filled
  • Ball Bearings – dual, high-carbon chromium steel
  • Power cable length – 25’ (8 m)

Note: Product information presented here reflects conditions at time of publication. Consult factory regarding discrepancies or inconsistencies.
