150 Series Effluent Pumps

  • Durable, cast iron construction
  • Model 151 (60 Hz) comes standard with a glass-filled, polypropylene base
  • Corrosion-resistant, powder coated epoxy finish
  • Stainless steel lifting handle
  • Assembled with stainless steel bolts
  • Non-clogging, engineered thermoplastic, vortex impeller design
  • Model 151 (60 Hz) – 1/3 HP, passes 1/2″ (13 mm) spherical solids
  • Model 152 – 4/10 HP (0.56 KW), passes 3/4″ (19 mm) spherical solids
  • Model 153 – 1/2 HP (0.71 KW), passes 3/4″ (19 mm) spherical solids
  • Motor – 3450 RPM, oil-filled, hermetically-sealed, automatic reset thermal overload protected
  • Carbon/Ceramic seals
  • Upper sleeve bearing and lower ball bearing running in bath of oil
  • 20′ (6 m), UL listed power cord with molded, 3-wire plug
  • 1-1/2″ NPT vertical discharge
  • BN and BE standard models include a 20′ (6 m), variable level float switch
  • Operates at temperatures to 130 °F (54 °C) in effluent applications
  • All models include a 1-1/2″ x 2″ PVC adapter fitting
  • 3 year limited warranty

Consult Factory for Special Applications:

  • Timed dosing panels
  • Electrical alternators for duplex systems are available and supplied with an alarm
  • Variable level control switches are available for controlling 1 Ph systems
  • Double piggyback, variable level float switches are available for variable level, long and short cycle controls
  • Sealed Qwik-Box available for outdoor installations – See FM1420
  • Over 130 °F (54 °C) – special quotation required
