260 Series Sewage Pumps

Submersible sewage, effluent or dewatering pump

Category:
Motor 1/2 HP
Voltage 115 – 460 V
Phase 1 or 3 Ph
Hertz 60 Hz
RPM 1750 RPM
Type Split phase or 3 phase
Insulation Class B
Amps 1.5 – 9.4 Amps
Operation Automatic or nonautomatic
Auto On / Off Points 12″ / 4″ (30 cm / 10 cm)
Discharge Size 2″ NPT
Solids Handling 2″ (50 mm) spherical solids
Cord Length 10′ (3 m) auto, 15′ (5 m) nonauto standard
Cord Type UL listed, 3-wire neoprene cord and plug
Max Head 21.5′ (6.6 m)
Max Flow Rate 128 GPM (484 LPM)
Max Operating Temperature 130 °F (54 °C)
Cooling Oil filled
Motor Protection Auto reset thermal overload (1 Ph)
Cap Cast iron
Motor Housing Cast iron
Pump Housing Cast iron
Base Cast iron or engineered plastic
Upper Bearing Sleeve bearing
Lower Bearing Sleeve bearing
Mechanical Seals Carbon and ceramic
Impeller Type Non-clogging vortex
Impeler Engineered plastic with metal insert
Hardware Stainless steel
Motor Shaft AISI 1215 cold rolled steel
Gasket Neoprene
  • Float-operated, 2-pole mechanical switch
  • Durable cast construction, ASTM Class 25 cast iron switch case and pump housing
  • Cast iron base on model 267
  • Engineered plastic base on model 266
  • Non-clogging vortex impeller design. Engineered plastic impeller with metal inserts (1 Ph). Model 267 available with cast iron impeller (standard on 3 Ph models).
  • Not affected by materials normally found in drainage and sewage pumps
  • Stainless steel screws, bolts, handle, guard and arm and seal assembly
  • Neoprene square ring and gasket
  • Oil-filled, hermetically-sealed motor
  • Oil-lubricated bearings
  • Carbon and ceramic shaft seal
  • Passes 2” (50 mm) spherical solids
  • 2” female discharge
  • On point: 12” (30 cm) (automatic units)
  • Off point: 4” (10 cm) (automatic units)
  • Corrosion-resistant, powder coated epoxy finish
  • Completely submersible
  • Watertight and dust-tight
  • Automatic and non-automatic models available
  • Models available packaged with a piggyback variable level float switch
  • Automatic reset thermal overload protection (1 Ph only)
  • 3 year limited warranty on Model 266 & 267

Consult factory for special applications:

  • Minimum recommended basin size (small load applications): simplex 18” x 30” (45.7 x 76.2 cm), duplex 30” x 36” (76.2 x 91.4 cm)
  • High water alarms available
  • Standard 266 model: 41 lbs (19 kg)
  • Standard 267 model: 47.5 lbs (21.5 kg)
  • Approximate gallons pumped out per cycle for standard models:
Tank Diameter Gallons / Liters Pumped
18” (45.7 cm) simplex 8 gallons / 36 liters
24” (61 cm) simplex 15 gallons / 68 liters
30” (76 cm) duplex 22 gallons / 100 liters
36” (76 cm) duplex 33 gallons / 150 liters
48” (122 cm) duplex 60 gallons / 273 liters

* May be used in those states where codes do not restrict solids size in effluent systems.

** See charts for UL and CSA listings.

Notes
The sizing of effluent systems normally requires variable level float(s) controls and properly sized basins to achieve required pumping cycles or dosing timers with non-automatic pumps.

Reserve powered design.

For unusual conditions a reserve safety factor is engineered into the design of every Zoeller® pump.
