RH/RA Series Clamp-on Direct Drive Mixers

The RH/RA Series direct drive mixers feature light weight yet very strong aluminum bearing housings for continuous, maintenance-free mixer service. The mixers are excellent for moderate shearing or liquid blending applications from 25 to 1000 gallons. A heavy duty SKF American made sealed ball bearing absorbs shaft deflection loads and provides extended mixer service. Sealed bearing assemblies are rated to 100,000 hours. With a dual bearing supported shaft coupling the RH/RA product line is well suited to toward long, over hung shaft lengths. Precision cast, square pitch industrial mixing propellersare standard.

Category:

The RH/RA Series direct drive mixers feature light weight yet very strong aluminum bearing housings for continuous, maintenance-free mixer service. The mixers are excellent for moderate shearing or liquid blending applications from 25 to 1000 gallons. A heavy duty SKF American made sealed ball bearing absorbs shaft deflection loads and provides extended mixer service. Sealed bearing assemblies are rated to 100,000 hours. With a dual bearing supported shaft coupling the RH/RA product line is well suited to toward long, over hung shaft lengths. Precision cast, square pitch industrial mixing propellersare standard.

  • Motors– American made Baldor motors are standard in 115/230/60/1 or 208/230/460/60/3 TEFC
    – Optional Motors include:
    – 1150 RPM
    – Inverter Duty, Explosion Proof, Chemical Duty, Washdown, or Premium Efficiency
    – 50Hz and other special voltages
  • Air Motors– Self-sealed, cast iron bodied
    – Inherent variable speed with needle valve.
    – Horsepower ranges from ¼ to 5 HP.
    – Speed ranges from 60-2000 rpm.

Options

  • AC and DC Variable Speed Drives

  • Specialty coatings on shafts and propellers for corrosive environments
  • Polished shafts and propellers for sanitary environments such as food or pharmaceutical production
  • Special finishes on mixer heads including white epoxy and “Steel-it” stainless steel paint
  • Cup plate mount is available at no additional cost. The advantage of cup plate mounting is an exceptionally sturdy bolted mounting base.

mixers

  • 100% Process Guarantee

  • 3 Year Mechanical Warranty

  • All Motors are Standard NEMA C-Face Design

  • C-Clamp Mount Design or Cup Plate Mount for no additional charge

  • All Shafts are 316SS, Pump Shaft Quality for Minimum Vibration, 32 RA Standard Finish

  • Impellers are 316SS

  • Special Coatings are Available (PVC, PFA, PVC, Halar, Rubber/Others on Request)

  • USDA Approved Sanitary Versions Available

  • OSHA Approved for Safety

Options

  • AC and DC Variable Speed Drives

  • Specialty coatings on shafts and propellers for corrosive environments

  • Polished shafts and propellers for sanitary environments such as food or pharmaceutical production

  • Special finishes on mixer heads including white epoxy and “Steel-it” stainless steel paint

  • Cup plate mount is available at no additional cost. The advantage of cup plate mounting is an exceptionally sturdy bolted mounting base
