Magnetic Drive Pumps Magnatex MP/MPL Series

Products – MPL / MP Series
Compact MPL/MP series magnetic drive pumps are the efficient and dependable choice for medium-flow, medium to high head applications. MPL Series magnetic drive pumps’ process side conforms to ANSI B73.3 dimensions. MP Series magnetic drive pumps feature sub-ANSI sizes for efficient lower flow applications. Affordable, top-performing Magnatex® magnetic drive pumps give you higher efficiency with lower horsepower and lower total cost of ownership.

Category:

Products – MPL / MP Series
Compact MPL/MP series magnetic drive pumps are the efficient and dependable choice for medium-flow, medium to high head applications. MPL Series magnetic drive pumps’ process side conforms to ANSI B73.3 dimensions. MP Series magnetic drive pumps feature sub-ANSI sizes for efficient lower flow applications. Affordable, top-performing Magnatex® magnetic drive pumps give you higher efficiency with lower horsepower and lower total cost of ownership.

The straddle-mounted double bearing design reduces shaft load and bearing wear over typical cantilevered, overhung designs.

  • Max. Flow: 340 gpm
  • Max. Head: 400 feet TDH
  • Temperature: -100° to 300°F
  • Max. Power: 20 hp
  • Materials of Construction:
      1. 316 Stainless Steel
      1. Alloy 20
      1. Titanium
      1. Hastelloy C
  • Connections: 150 LB RF Flanges
    • Bearings:
        Silicon Carbide Dry-Run (MP)
        Silicon Carbide (MPL)
  • Impeller: Enclosed
  • Speeds: 1800 and 3600 rpm
  • Magnets: Neodymium
  • Motor: Close-coupled, standard C-face
