2″ X 2″ 316 Self Priming Pump

Designed to provide a more robust and compact design, the Double Seal Flomax self priming centrifugal pump models provide excellent solutions to any OEM, industrial, or agricultural application. The patent pending design of this pump has the barrier fluid accumulator located directly on the body, resulting in decreased system costs and greater pump reliability.

Category:

A FLOMAX® 8, 316 SS PumPAK® is a fully assembled and run tested pump end that can be easily coupled to a number of drivers such as hydraulic motors, 56C and 145TC frame motors and gas engines. A bearing pedestal is also available for T-frame motor or belt drive.

Standard features include a 2″ NPT 150# class flat flange on the suction of the pump, a Viton flapper, 2″ SAE 4-bolt flat face discharge connection, stainless steel drive sleeve, stainless steel fasteners, renewable 316 SS wearplate, and a semi-open dynamically balanced 316 SS impeller. Options include a 5-blade high flow 316 stainless steel impeller and seals for all types of abrasive and/or corrosive services.

The FLOMAX® series of pumps are commonly used in Industrial, OEM, Agricultural and Marine applications, such as: Bilge Pumps, Auxiliary Fire Pumps, Ballast Transfer Pumps, Washdown Pumps, Fertilizer and Pesticide Pumps, Applicators & Sprayers, Blending Pumps, Nurse Tanks, Bulk Transfer Pumps and much more.

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

self priming centrifugal pump

PDF Logo3001-floma

PDF Logoflomax-8-self-priming-centrifugal-pump

PDF Logo3002F-flomax-pumpak

PDF LogoFlomax-5-and-8-Type-Approval







APPLICATION
Agricultural, Industrial, Marine, OEM
MATERIALS OF CONSTRUCTION
316 stainless steel
FLOW
Up to 150 GPM
HEAD FEET
UP to 100′
IMPELLER
5.0″ max. diameter, semi-open
MOTOR
Up to 3HP
DRIVE OPTIONS
Close coupled to 145TC, Close Coupled to 56C, Engine mount to 5.5HP, Engine mount to 6.5HP, Pedestal, PumPAK® (without motor)
SEAL
Carbon/Ceramic/Viton, Special seal material combinations available (consult factory)
FEATURES
Renewable wear plate, Up to 25′ suction lift
OPTIONS
5 blade impeller for higher flows, Available 2″ NPT ANSI 150# class discharge flange kit (p/n: 36607), Hydraulic motor .37 cu. in., Hydraulic motor .45 cu. in., Hydraulic motor .58 cu. in.
SUCTION
2″ NPT ANSI 150# class flat flange with Viton flapper
DISCHARGE
2″ ANSI 4-bolt flange connection, Optional 2″ NPT ANSI 150# Flange Available.Part number for Optional ANSI Discharge Flange Kit: 36607
