2″ x 2″ Self Priming Pump

Once primed, the FLOMAX® 8 self priming centrifugal pump is able to keep a full column of liquid in the suction line with a flapper valve. Up to 25 feet of lift can be created from the technology found inside this self priming pump. The centrifugal pump contains stainless steel fasteners and drive shaft; making it perfect for every application inside the industrial, OEM, agricultural and marine industries.

Category:

A FLOMAX® 8 PumPAK® is a fully assembled and run tested pump end that can be easily coupled to a number of drivers such as hydraulic motors, 56C and 145TC frame motors and gas engines. A bearing pedestal is also available for T-frame motor or belt drive.

Standard features include stainless steel drive sleeve, stainless steel fasteners, renewable wearplate, and a semi-open dynamically balanced impeller.

The FLOMAX® series of pumps are commonly used in Industrial, OEM, Agricultural and Marine applications, such as: Bilge Pumps, Auxiliary Fire Pumps, Ballast Transfer Pumps, Washdown Pumps, Fertilizer and Pesticide Pumps, Applicators & Sprayers, Blending Pumps, Nurse Tanks, Bulk Transfer Pumps and much more.

SUCTION AND DISCHARGE
2″ x 2″ NPT
APPLICATION
Agricultural, Industrial, Marine, OEM
MATERIALS OF CONSTRUCTION
316 stainless steel, Aluminum, Bronze, Cast iron
FLOW
Up to 150 GPM
HEAD FEET
UP to 100′
IMPELLER
5.0″ max. diameter, semi-open
MOTOR
Up to 3 HP
DRIVE OPTIONS
Close coupled 56C, Engine mount 5.5 HP, Engine mount 6.5 HP, Close coupled 145TC, Pedestal, PumPAK® (without motor)
SEAL
Special seal material combinations available (consult factory), Standard carbon / ceramic / Viton
MAX SOLID SIZE
.56″
OPTIONS
5 blade impeller available for higher flows, Base plate shown above is optional, Double seal available for dry run applications, Flanges not included on S.S. models, Hydraulic motor .37 cu. in., Hydraulic motor .45 cu. in., Hydraulic motor .58 cu. in.
FEATURES
Renewable wear plate, Stainless steel drive sleeve, Stainless steel fasteners, Up to a 25′ suction lift
